The 80MM Drone Dropper is a precision delivery system compatible with 80 mm shells (3.4 kg each), featuring bottom-up impact installation and 2-10 round capacity.
Key Capabilities
- Compatible with 80 mm shells (3.4 kg each)
- 2–10 round loading capacity
- Automatic single-round or full deployment
- 1-3 meter casting accuracy
- 5-10 km control distance
- Bottom-up impact type automatic card lock installation
- Built-in safety unlock mechanism
- Expandable configurations: 2, 4, 6, 8, or 10 rounds
Technical Specifications
| Compatible shell type | 80 mm (3.4 kg each) |
|---|---|
| Loading capacity | 2–10 shells |
| Dimensions | 305 × 130 × 265 mm (2 rounds) to 310 × 510 × 265 mm (10 rounds) |
| Net weight | 1.5 kg (2 rounds) to 6 kg (10 rounds) |
| Material | Aviation aluminum, carbon fiber, 304 stainless steel |
| Installation mode | Bottom-up impact type automatic card lock |
| Throw mode | Automatic single throw or all throw |
| Working voltage | DC 12-80V |
| Signal mode | SBUS/PWM/TTL |
| Casting accuracy | 1–3 m |
| Control distance | 5–10 km |
| Expanded quantity | 2, 4, 6, 8, 10 rounds |
Applications
Heavy payload precision delivery, tactical deployment, emergency supply distribution, and multi-round payload operations from drone platforms.
Deployment note: Final configuration, operator training, airspace approval, and local regulatory compliance are required before deployment.
