A handheld drone detection and deception device with 600 MHz to 6 GHz detection band, GPS/GLONASS spoofing capability, and ≥1 km deception range in a 710 g portable package.
Key Capabilities
- 600 MHz – 6 GHz detection frequency band
- Digital and analog image transmission detection modes
- Detects common consumer-grade drones (600 MHz – 6 GHz analog)
- >1.2 km digital image transmission detection, >1.5 km analog
- GPS L1 and GLONASS G1 deception (BDS B1, Galileo E1 customizable)
- ≥1 km deception effective range
- ≤15 W overall power consumption
- Battery-powered with hot-swappable battery
- ≥4 hour standby time, 710 g weight
Technical Specifications
| Detection frequency band | 600 MHz – 6 GHz |
|---|---|
| Detection mode | Digital image transmission / analog image transmission |
| Detectable drones | Common consumer-grade, analog 600 MHz – 6 GHz |
| Detection distance | >1.2 km digital, >1.5 km analog |
| Deception bands | GPS L1, GLONASS G1 (BDS B1, Galileo E1 customizable) |
| Signal transmission power | 10 mW |
| Deception effective range | ≥1 km |
| Overall power consumption | ≤15 W |
| Power supply | Battery-powered, swappable |
| Standby time | ≥4 h |
| Operating temperature | -20°C to +55°C |
| Product weight | 710 g ± 5 g |
| Product dimensions | 223 × 77 × 42 ± 2 mm |
Applications
Portable drone detection and spoofing, personal security operations, field-deployable counter-UAV, and rapid-response airspace protection.
Deployment note: Final configuration, operator training, airspace approval, and local regulatory compliance are required before deployment.
