A multi-band detection and countermeasure gun combining 2.4/5.8 GHz drone detection with 5-channel countermeasure jamming, ≥1,500 m detection, and ≥1,000 m countermeasure range.
Key Capabilities
- 2.4 GHz and 5.8 GHz detection frequency bands
- ≥1,500 m detection range for consumer and industrial drones
- ≤5 second detection response time
- 5-channel countermeasure: 840-930, 1550-1620, 2400-2500, 5150-5350, 5725-5850 MHz
- ≥1,000 m countermeasure range
- 360° detection, 30° countermeasure operating angle
- ≥15 sorties multi-target detection and jamming capacity
- ≤5 second countermeasure response time
- 10:1 jamming-to-communication ratio
- ≥30 minute battery life, ≤7 kg, IP65
Technical Specifications
| Detection frequency band | 2.4 GHz, 5.8 GHz |
|---|---|
| Detectable drones | Conventional consumer-grade and industrial drones |
| Detection range | ≥1,500 m |
| Detection response time | ≤5 s |
| Countermeasure bands | Ch1: 840-930, Ch2: 1550-1620, Ch3: 2400-2500, Ch4: 5150-5350, Ch5: 5725-5850 MHz |
| Countermeasure range | ≥1,000 m |
| Operating angle | 360° detection, 30° countermeasure |
| Multi-target capacity | ≥15 sorties |
| Countermeasure response time | ≤5 s |
| Jamming-to-communication ratio | 10:1 |
| Battery life | ≥30 min |
| Operating temperature | -20°C to +60°C |
| Protection level | IP65 |
| Product weight | ≤7 kg |
| Product dimensions | 430 × 345 × 188 ± 5 mm |
Applications
Integrated drone detection and countermeasure, rapid-response counter-UAV operations, event security, and handheld airspace protection.
Deployment note: Final configuration, operator training, airspace approval, and local regulatory compliance are required before deployment.
