A vehicle-mounted drone jamming system with 300 MHz to 6 GHz detection band, ≥5 km detection range, and ≥3 km jamming distance across multiple frequency bands.
Key Capabilities
- 300 MHz – 6 GHz detection frequency band
- ≥5 km detection range with ≥1.5 km FPV video link detection
- 0–1,200 m detection altitude
- Multi-band jamming: 900 MHz, 1.2 GHz, 1.5 GHz, 2.4 GHz, 5.2 GHz, 5.8 GHz
- ≥3 km jamming distance
- 360° azimuth, -90° to +90° elevation jamming coverage
- ≥24 hour operating duration
- (-20°C to +60°C) ±2°C operating temperature
Technical Specifications
| Detection frequency band | 300 MHz – 6 GHz |
|---|---|
| Detection range | ≥5 km |
| FPV video link detection | 500 MHz – 6 GHz |
| Video link detection range | ≥1.5 km |
| Detection altitude | 0–1,200 m |
| Jamming frequency bands | 900 MHz, 1.2 GHz, 1.5 GHz, 2.4 GHz, 5.2 GHz, 5.8 GHz |
| Jamming distance | ≥3 km |
| Jamming coverage | Azimuth 360°, elevation -90° to +90° |
| Operating duration | ≥24 h |
| Operating temperature | (-20°C to +60°C) ±2°C |
| Weight | 64.25 kg |
| Dimensions | 800 mm × 600 mm |
Applications
Vehicle-mounted counter-drone operations, mobile airspace security, convoy protection, and rapid-deployment jamming for event security.
Deployment note: Final configuration, operator training, airspace approval, and local regulatory compliance are required before deployment.
